| CODE | DIA | BORE | Z | WOOD THICK |
|---|---|---|---|---|
| YT17 A 101 | 125/150 | 30/31.75 | 4 | 32-40 |
| YT17 A 102 | 125/150 | 30/31.75 | 4 | 32-40 |
| YT17 A 103 | 125/150 | 30/31.75 | 4 | 32-40 |
| YT17 A 104 | 125/150 | 30/31.75 | 4 | 32-40 |
| YT17 A 105 | 125/150 | 30/31.75 | 4 | 32-40 |
| YT17 A 106 | 125/150 | 30/31.75 | 4 | 32-40 |
This tool is available in both Brazed & Replaceable Knives variety. Brazed has carbide of special 5 mm thickness, to make several re-sharpening possible.
| CODE | DIA | BORE | Z | WOOD THICK |
|---|---|---|---|---|
| YT19 B 101 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 R 101 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 B 102 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 R 102 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 B 103 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 R 103 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 B 104 | 125/200 | 30/35 | 4/6 | 40-50 |
| YT19 R 104 | 125/200 | 30/35 | 4/6 | 40-50 |
The heads for making profiles & counter profiles are fitted with profiled Knives 1 & 2 are then interchangeable. Extra long tenons-gives good quality of door-working while making doors very study By Yash Tooling System In Ahmedabad, India.
| CODE | DIA | BORE | Z | WOOD THICK |
|---|---|---|---|---|
| YT18 101 | 125/200 | 30/35 | 2/3 | 32-40 |
| YT18 102 | 125/200 | 30/35 | 2/3 | 32-40 |
| YT18 103 | 125/200 | 30/35 | 2/3 | 32-40 |
| YT18 104 | 125/200 | 30/35 | 2/3 | 32-40 |
| YT18 105 | 125/200 | 30/35 | 2/3 | 32-40 |
| YT18 106 | 125/200 | 30/35 | 2/3 | 32-40 |
| Knives | Screw | Spure | Screw | Knives | Wedge | Stopper |
|---|---|---|---|---|---|---|
| 20x30x2 | M8x12 | 14x14x2 | M5x2C | 7.5x12x1.5 | 12x12x7 | M5x8B |
The heads for making profiles & counter profiles are fitted with profiled Knives 1 & 2 are then interchangeable. Extra long tenons-gives good quality of door-working while making doors very study.
| CODE | DIA | BORE | Z | WOOD THICK |
|---|---|---|---|---|
| YT17 101 | 125/200 | 30/35 | 4/6 | 32-40 |
| YT17 102 | 125/200 | 30/35 | 4/6 | 32-40 |
| YT17 103 | 125/200 | 30/35 | 4/6 | 32-40 |
| YT17 104 | 125/200 | 30/35 | 4/6 | 32-40 |
| YT17 105 | 125/200 | 30/35 | 4/6 | 32-40 |
| YT17 106 | 125/200 | 30/35 | 4/6 | 32-40 |
